Features:

• LED Shadow Cut Line for 100% accurate cut and better illumination
• Sliding mechanism provides up to 310mm cutting capacity to meet all application requirements
• Double bevel head for great cutting versatility

Specifications:

• Power Input: 1800W
• Blade Diameter: 254mm
• Blade Kerf Thickness: 2.8mm
• Bore Diameter: 25.4mm
• Max. Blade Speed: 4800min-1
• Mitre (Max. Positions): Left – 47 / Right – 52
• Bevel (Max. Positions): Left – 45 / Right – 45
• 0 mitre, 0 bevel: 92mm x 285mm / 80mm x 310mm
• 45 mitre, 0 bevel: 92mmx190mm / 80mmx210mm
• 0 mitre, 45 bevel left: 47mmx285mm / 45mmx310mm
• 45 mitre, 45 bevel left: 47mmx190mm / 45mmx210mm
• 0 mitre, 45 bevel right: 35mmx285mm / 25mmx310mm
• 45 mitre, 45 bevel right: 35mmx190mm / 25mmx210mm
• Automatic Blade Brake Time: <10.0 sec
