Name: SPI Dial Test Indicators (Vertical)
SKU: TEEYuq75A3lNL
Availability: InStock

Sale!

SPI Dial Test Indicators (Vertical)

SPI Dial Test Indicators (Vertical) Features: Horizontal and Vertical type Universal positioning capability Fully jeweled movement Easy to read dial Satin chrome finish Contact point: 0.080" dia. x 1/2" length Contact point pivot: 100 degrees Dovetail stem

$66.23 $132.45

SPI Dial Test Indicators (Vertical)

Features:

Horizontal and Vertical type
Universal positioning capability
Fully jeweled movement
Easy to read dial
Satin chrome finish
Contact point: 0.080″ dia. x 1/2″ length
Contact point pivot: 100 degrees
Dovetail stems: 5/32″ (8 mm) and 3/8″ (6 mm) dia
Certificate of calibration traceable to NIST
furnished in fitted case

Specifications:

Item Number Max Measuring Range Graduation Dial Diameter Dial Reading 14-656-3 0.02″ 0.0005″ 1-1/4″ 0-10-0 14-658-9 0.03″ 0.0005″ 1-1/4″ 0-15-0 14-660-5 0.008″ 0.0001″ 1-1/4″ 0-4-0 14-663-9 0.2 mm 0.002 mm 32 mm 0-100-0 14-666-2 0.5 mm 0.01 mm 32 mm 0-25-0 14-670-4 0.8 mm 0.01 mm 32 mm 0-40-0 14-673-8 1.0 mm 0.01 mm 32 mm 0-50-0
