100% Copper
Thermally-Protected
Application Fields
- Building/construction work/Domestic water supply;
- Irrigation and Small water work;
- Landscaping;
- Water conservancy system;
- Factory.
Features
- Edible oil filled motor, stable& reliable running with pressure regulating membrane;
- Single phase motor equipped with start box which built in capacitor ¤t mode thermal protector, convenient for replacement;
- Available with cable with a motor plug, disassemble conveniently;
- Pump sleeve with screw thread, single stage floating impellers, except 16 m3/hrs series which with integrated stage floating impellers;
- Installation in 4″ or larger boreholes;
Specifications
| Model |
X4SGm6/6-1.1 |
X4SGm6/8-1.5 |
X4SGm8/9-2.2 |
| Rated Power (HP) |
1.5 |
2 |
3 |
| Outlet (Inches) |
1.25″ |
1.25″ |
1.25″ |
| Rated Flow (m3/h) |
6 |
6 |
6 |
| Rated Head (m) |
41 |
55 |
60 |
| Max Flow (m3/h) |
9.6 |
9.6 |
10.8 |
| Max Head (m) |
49m |
66m |
73m |
| Cable (m) |
4×1.5-2.3m |
4×1.5-2.3m |
4×2-3.3 |
| Price |
9,625.00 |
11,100.00 |
12,600.00 |
Application Limits
- Max. ambient temperature< 40C;
- Sand content(in mass fraction)up to 0.01%;
- hydrogen sulfide content up to 1.5mg/L, chlorideion content up to 400mg/L;
- pH 6.5 to 8.5;
- Maximum: 70 m below the static water table.
