FEATURES:
- Ultra compact and slim design at only 135 mm (5-5/16) long
- Ultra lightweight for reduced operator fatigue
- Power-increased motor delivers 135 Nm (1,200 in.lbs.) of Max Torque in an ultra compact size
- 3-Mode operation: A-mode / Hard mode / Soft mode for multiple applications
- A-Mode feature helps eliminate screw cam-out and cross threading by driving at low speed until tightening begin
Bare Tool – Battery and Charger not yet included
SPECIFICATIONS:
| Net weight |
0.97 1.1 kg (2.1 2.5 lbs) |
| Dimensions (L x W x H) |
135x66x210 mm (5-5/16×2-5/8×8-1/4) |
| Sound Power Level |
105 dB(A) |
| Sound Pressure Level |
94 dB(A) |
| Vibration Level |
Impact tightening of fasteners of the maximum capacity of the tool: 12.5 m/s |
| Max Fastening Torque |
135 Nm (1,200 in.lbs.) |
| Impacts Per Minute (IPM) |
Hard / Soft: 0 3,900 / 0 1,600 |
| No Load Speed (RPM) |
Hard / Soft: 0 3,000 / 0 1,300 |
| Hex Shank |
6.35 mm (1/4) |
|
Coarse thread (in length): 22 90 mm (7/8 3-1/2) |
|
High Tensile Bolt: M5 M12 (3/16 1/2) |
|
Standard Bolt: M5 M14 (3/16 9/16) |
| Capacity |
Machine Screw: M4 M8 mm (5/32 5/16) |
