FEATURES:
- Excellent tool balance for easy handling and control
- Anti-Vibration Technology (AVT) for extremely low vibration
- High power similar to DHR282 series
- Auto-start Wireless System (AWS) connects to vacuum cleaner with Bluetooth
- Active Feedback sensing Technology (AFT) turns the motor off if bit rotation is suddenly forced to stop
- Soft no load function automatically reduces the motor speed during idling to suppress the vibration
- 3-mode operation for Rotation Only, Hammering with Rotation or Hammering Only
- One touch sliding chuck enables quick and easy bit changes
- Variable speed trigger allows operator to adjust speed based on materials or application
- Constant speed control automatically applies additional power to the motor to maintain speed under load
- Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
- Electric brake for maximum productivity and increased operator safety
- Twin LED lights with preglow and afterglow functions illuminate drilling surface for more productivity in low light applications
- Reverse switch operable by one hand
- eXtreme Protection Technology (XPT) is engineered for improved dust and water resistance for operation in harsh conditions
- Battery protection circuit protects against overloading, over-discharging and over-heating
- Depth gauge for increased drilling consistency
Bare Tool – Battery and charger not included
SPECIFICATIONS:
| Impact Energy |
EPTA-Procedure 05/2009:2.8 J |
|
Our experimental conditions:3.2 J |
| Capacity |
Concrete/Steel/Wood/Core Bit/Diamond Core Bit (Dry Type): 28/13/32/54/65mm (1-1/8/1/2/1-1/4/2-1/8/2-9/16) |
| Blows Per Minute (BPM) |
0 5,000 |
| No Load Speed (RPM) |
0 980 |
| Max Output |
620 W |
| Chuck Capacity |
1.5 13 mm (1/16 1/2) |
| Vibration Level |
Hammer Drilling into Concrete:7.0 m/s |
|
Hammer Drilling into Concrete w/ DX12:7.0 m/s |
|
Chiselling Funtion w/ Side Grip:6.5 m/s |
|
Drilling into Metal:2.5 m/s or less |
| Vibration K Factor |
1.5 m/s |
| Sound Pressure Level |
95 dB(A) |
| Sound Power Level |
106 dB(A) |
| Noise K Factor |
3 dB(A) |
| Sound Pressure Level |
w/ DX12:93 dB(A) |
| Sound Power Level |
w/ DX12:104 dB(A) |
| Noise K Factor |
w/ DX12:3 dB(A) |
| Dimensions (L x W x H) |
w/ BL4025:358x102x232 mm (14-1/8x4x9-1/8) |
|
w/ BL4040:373x102x238 mm (14-3/4x4x9-3/8) |
| Net Weight |
3.9 4.6 kg (8.6 10.1 lbs.) |
