Specifications:
| Fuel tank |
520ml
|
| Tank for chain lubrication Oil |
260ml
|
| Fuel (Mixture oil) |
25: 1:2- cycle engine oil
|
| Oil (Chain oil) |
Special chain oil or motor oil
|
| Usable cutting length of guide bar: |
550/22
|
| Type of Guide bar |
Sprocket nose
|
| Lubrication |
Adjustable automatic oil pump
|
| Sprocket: Specifled number of teeth |
7
|
| Maximum chain speed |
23.6 m/s
|
| Type: |
Air cooled 2 cycle single cylinder
|
| Carburetor |
Diaphragm type Walbro WT664
|
| Magneto: |
Flywheel magneto, CDI HX100
|
| Starter: |
Recoil starter
|
| Max. Speed with cutting Attachment |
11000 r/min
|
| Speed at idling |
3000200
|
| Engine Displacement |
54
|
| Fuel Consumption: at max. engine power |
530
|
| Sound pressure level: (IS07182) LpAav |
104
|
| Guaranteed sound power level (ISO9207) LwAav |
114
|
| Chain Brake (ISO6535) Mean braking time at racing speed |
0.10
|
| Vibration: ( ISO7505) |
10.8
|
| Other Devices: |
Front hand guard, Rear hand guard, Throttle trigger lockout, Chain catcher, Chain brake, Anti-vibration device, Spiked Bumper.
|
3 Months Service Warranty
