Working range*

100m

Working range with receiver*

300 m (Diameter)

Accuracy*

0.1 mm/m

Laser diode

532 nm, < 5 mW

Operating temperature, from

0C

Operating temperature, up to

40C

Operating temperature

0 40C

Storage temperature, from

-20C

Storage temperature, up to

70C

Storage temperature

-20 70C

Laser class

3R

Working range with receiver, value

300m

Working range with receiver, appendage

(Diameter)

Working range without receiver, value

100m

Working range without receiver, appendage

(Diameter)

Working range without receiver

100 m (Diameter)

Self-levelling range

5 (8%)

Levelling time

15s

Dust and splash protection

IP 54

Rotation speed

150, 300, 600 rpm

Power supply

2 x 1.2 V HR20 (D) (9 Ah), 2 x 1.5 V LR20 (D)

Operating time (max.)

Rechargeable batteries (NiMH) 20 h

Tripod thread

5/8″

Weight, approx.

1.8kg

Colour of laser line

green

Compatible laser receivers

LR 1G
